Suction cup lifts

Eberle suction cup lifters: professional solutions for every lifting need

For over 30 years, Eberle has been designing and building the highest quality suction cup lifters, standing out in the sector for the reliability of the solutions offered and the ability to respond to the most complex needs of the industrial, construction and craft market.

State-of-the-art vacuum technology

Our suction cup lifters represent the evolution of decades of experience in the safe handling of smooth and flat materials. Thanks to vacuum technology, we guarantee a uniform and distributed grip that protects the integrity of the lifted materials, eliminating the risks of damage which are typical of mechanical gripping systems.

Vacuum generation systems

  • We offer a range of technological solutions to meet every operational requirement:
  • Electric pumps: for continuous industrial applications with mains power supply
  • Compressed air Venturi systems: an economical and clean solution for environments equipped with a pneumatic system
  • Battery-powered systems: maximum mobility for construction sites and applications where a fixed power supply is not available

Lifting capacity

Our experience has allowed us to achieve exceptional performances:

  • Lifting elements up to 17 metres in length
  • Load capacity up to 10 tonnes
  • Accurate certifications based on rigorous tests conducted in collaboration with the University of Padua

Each suction cup is subjected to practical and theoretical detachment tests, guaranteeing high safety coefficients for use in construction sites and production plants.

Application versatility without any compromise

Our suction cup lifters stand out for their exceptional versatility. While initially the suction cups were mainly used for perfectly smooth materials, today our technology allows us to lift:

Traditional materials

  • Glass: from small slabs to large structural windows
  • Marble and natural stone: with suction cups equipped with special mousses for porous surfaces
  • Sheet metal: steel and aluminium, with heat-resistant rubbers for freshly processed sheets

Innovative materials

  • Sandwich panels and insulated materials for modern construction
  • Wood: MDF, chipboard and panels, thanks to high-performance Venturi Systems
  • Ceramics and porcelain: a fast-growing sector with dedicated solutions
  • Special materials: plasterboard, polystyrene, concrete slabs

Advantages of suction cup lifters

Using an Eberle suction cup lifter offers several operational advantages:

  • Higher versatility compared to magnets: unlike magnetic systems, suction cups lift different materials such as steel, aluminium, marble and glass, ensuring precision and reliability
  • Safe and selective handling: our suction cups allow you to lift individual sheets of material, avoiding the accidental gripping of multiple elements, as can happen with magnets
  • Energy and functional efficiency: in addition to the classic electric models, we have innovative Venturi systems powered by compressed air, which guarantee high performance without the need for large pumps
  • Safety and certified reliability: every Eberle suction lift is subjected to rigorous tests, with practical detachment tests certified in collaboration with the University of Padua, guaranteeing maximum safety standards

Innovation and safety: our hallmark

An exclusive alarm system

We are the only manufacturer to have developed an acoustic-visual pneumatic alarm system that always works, without the need for batteries or power supply. This innovation, never successfully replicated by the competition, guarantees maximum operational safety in all conditions.

Regulatory compliance

All our suction cup lifters are designed and built in compliance with current safety regulations, with:

  • Conforms to UNI EN 13155 for lifting accessories
  • Certified vacuum storage tanks
  • Non-return valves to maintain the grip even in the event of a power interruption
  • Continuous vacuum level monitoring systems
  • Complete technical documentation and CE marking

PRODUCTION AND CUSTOMISATION

Fully internalised production in our factories allows us to:

  • Ensure the highest construction quality
  • Offer tailor-made customised solutions
  • Maintain competitive delivery times
  • Provide spare parts also for suction cups from 50 years ago

Our technical team collaborates with customers to develop ad hoc lifting systems, starting from the layout of production spaces and specific handling needs.

Comprehensive services for your company

Technical support and maintenance

The safety and efficiency of lifting systems depend on proper maintenance. That is why we offer a comprehensive support service that includes:

  • Mandatory scheduled maintenance according to current regulations
  • Specialized technical assistance on all lifting systems
  • Interventions on systems of any brand, not only Eberle
  • Dedicated teams of qualified technicians, our direct employees
  • Complete management of suction cups, cranes, and related accessories (rockers, ropes, chains)

Rental Service

For companies that need temporary solutions or want to test our systems before purchasing, we offer a large fleet of rental machines:

  • Suction cup lifters for different applications and flow rates
  • Immediate solutions for seasonal work or specific orders
  • Preliminary test opportunities in real operating conditions
  • Technical support throughout the rental period

Why Choose Eberle Suction Cup Lifters

Consolidated experience

over 30 years in the industry

Certified reliability

documented tests and evidence

Continuous innovation

state-of-the-art technical solutions

Comprehensive support

from design to after-sales service

Italian quality

in-house production with selected materials

Our suction cup lifters are the optimal choice for companies looking for safe, efficient, and durable handling solutions.

Contact us

Contact us to find out how our systems can optimise your production processes and improve safety at work.
